MSI RADEON RX 5600 3GTOC – GDDR5 GB GDDR6 192 bit

Key Specifications:

Feature	Specification
GPU / Architecture	AMD Navi 10, RDNA 1.0 (7 nm)
CUDA-equivalent / Stream / Compute Units	2304 stream processors
Memory	6 GB GDDR6
Memory Bus Width	192-bit
Peak Memory Speed	Up to ~ 14 Gbps in many MSI variants
Memory Bandwidth	Typically ~ 336 GB/s in higher memory speed variants; standard ~ 288 GB/s in earlier BIOS/specs
Clocks (Base / Game / Boost)	Varies by model: e.g. Gaming X variant: Base ~ 1420 MHz, Game ~ 1615 MHz, Boost ~ 1750 MHz, others like the Gaming MX have Base ~1280 MHz, Game ~1495 MHz, Boost ~1620 MHz
Bus Interface	PCI Express 4.0 ×16
Power Consumption (TGP / TDP)	~ 150 W typical for many MSI RX 5600 XT models
Power Connector(s)	Usually 1 × 8-pin or 2 × 8-pin depending on the model
Display Outputs	3 × DisplayPort 1.4, 1 × HDMI 2.0b
Max Display Resolution	Up to 7680 × 4320 (8K) over DisplayPort / HDMI depending on setup
Card Size / Dimensions	Depends on variant: for example, “Gaming MX” model is approx. 297 × 141 × 42 mm

Feature	Specification
GPU / Architecture	AMD Navi 10, RDNA 1.0 (7 nm)
CUDA-equivalent / Stream / Compute Units	2304 stream processors
Memory	6 GB GDDR5
Memory Bus Width	192-bit
Peak Memory Speed	Up to ~ 14 Gbps in many MSI variants
Memory Bandwidth	Typically ~ 336 GB/s in higher memory speed variants; standard ~ 288 GB/s in earlier BIOS/specs
Clocks (Base / Game / Boost)	Varies by model: e.g. Gaming X variant: Base ~ 1420 MHz, Game ~ 1615 MHz, Boost ~ 1750 MHz, others like the Gaming MX have Base ~1280 MHz, Game ~1495 MHz, Boost ~1620 MHz
Bus Interface	PCI Express 4.0 ×16
Power Consumption (TGP / TDP)	~ 150 W typical for many MSI RX 5600 XT models
Power Connector(s)	Usually 1 × 8-pin or 2 × 8-pin depending on the model
Display Outputs	3 × DisplayPort 1.4, 1 × HDMI 2.0b
Max Display Resolution	Up to 7680 × 4320 (8K) over DisplayPort / HDMI depending on setup
Card Size / Dimensions	Depends on variant: for example, “Gaming MX” model is approx. 297 × 141 × 42 mm

Excellent performance for 1080p and 1440p gaming, hitting high settings in most modern titles.
Strong in GPU-accelerated tasks like video editing, streaming, and content creation.
Good value proposition: strong performance per watt, especially in MSI’s overclocked variants.
Supports modern features: PCIe 4.0, VR-ready, high framerate, support for AMD features like FreeSync etc.

6 GB VRAM is solid, but newer AAA games and future titles may demand more for ultra/high texture settings or 4K gaming.
There are multiple MSI variants with differing clock speeds and memory speeds — lower spec versions will deliver less performance.
Requires decent power supply (150 W for GPU alone + rest of PC) and good case airflow to maintain boost clocks.
As GPUs age, driver updates & feature support can vary, so check support for the specific model you have.
